Explanation of carbon fiber regeneration technology
Column:Carbon fiber regeneration equipment
Date:2025-11-13
Visits:52
Desc:Explanation of carbon fiber regeneration technology
This question is quite profound. Carbon fiber regeneration technology is the core means to achieve the recycling and utilization of carbon fiber materials. Its core is to separate the fibers from the matrix resin in discarded carbon fiber products through physical, chemical, or thermal methods, restore the fiber properties, and then reuse them.
Technical Core Logic: Carbon fiber products are mostly composite materials of 'fiber + resin'. They cannot be reused directly after being discarded. The key of regeneration technology is to remove the resin matrix without seriously damaging the carbon fiber structure, while trying to retain the core properties of the fiber such as strength and modulus as much as possible.
Detailed Explanation of Mainstream Regeneration Technologies:
• Mechanical Recycling Technology: Through physical operations such as crushing, grinding, and sieving, fibers and resin are separated directly. Its advantages are simple process, low cost, no pollutant emissions, and suitability for processing batch discarded products; its disadvantages are that the fiber length is greatly shortened (mostly short-cut fibers), with a performance loss of about 30%-50%, and it can only be used in scenarios with low performance requirements.
• Pyrolysis Recycling Technology: In an oxygen-free or inert gas environment at 400-600℃, the resin matrix is thermally decomposed into small molecular gases and排出, leaving the carbon fiber. Its advantages are good retention of fiber length (long fibers can be recovered), a performance loss of only 10%-20%, and high recovery efficiency; its disadvantages are high equipment investment and the need to treat the exhaust gas generated from decomposition.
• Chemical Recycling Technology: Using organic solvents, catalysts, or high-temperature molten salts, the resin matrix is dissolved under mild conditions. Its advantages are that the fiber performance is close to virgin carbon fiber (loss below 10%), and the resin can be recycled simultaneously; its disadvantages are high solvent cost, complex recycling process, and limited large-scale application.
• Supercritical Fluid Recycling Technology: Using supercritical CO₂ and other media to assist in dissolving the resin. Its advantages are environmental protection, mild process, and minimal damage to fibers; its disadvantages are that the technology is still in the laboratory stage and has not achieved large-scale mass production.
Technical Development Trends:
• High-performance: By optimizing process parameters to reduce fiber performance loss and narrow the performance gap between regenerated fibers and virgin fibers.
• Low-cost: Simplify the recycling process, reduce equipment energy consumption, and solve the high-cost problems of chemical recycling and pyrolysis recycling.
• Integration: Develop a closed-loop process of 'recycling - regeneration - remanufacturing' to achieve seamless connection from discarded products to terminal products.
